Grounding Clips Solar Mounting Components
- Product Type: Solar Panel Grounding Systems Hardware
- Product Model: Solar-Panel-Grounding-Clips-8H
- Material: 304 Steel
- Max Wind Load : 60 m/s
- Max Snow Load : 1.4 KN / M 2
- Application: PV module Installation
Product Description :
Model : Solar-Panel-Grounding-Clips-SPC-GW-08
Solar Panel Grounding Clips (8H) is designed for earthing pv modules to aluminium rails .
8H stainless steel washer can be continuous grounding electrode conductor , be used to ground solar panels to grounded racking .
Do apply enough values of torque for PV grounding clips , so that teeth of electrical plates can penetrating surface of aluminum rails / carbon steel well .
Model 8H solar panel grounding clips is inserted between PV module frames and racking aluminum rails .
PV grounding washer is essential but easy for ignoring , Each solar installation project should have a well electrical earthing path to protect from electric shocking .
Advantages :
– Each PV modules would need one grounding clip ;
– New convenient / cost & labor effective in installation ;
– Well pierce surface of anodized coating with 8H solar grounding clip teeth around ;
– Anti-rusty SUS 304 stainless-steel made, reliable for outdoor application ;
– Long lifetime span for PV mounting system ;
– Custom specification design available as factory direct based .
If you’re interested in solar mounting components or solar system, we’d love to discuss with you about more and answer any questions you might have. As a professional manufacturer of PV mounting system, SPC is a great option for you.
Click here for more details and information:
www.SolarPartsComponents.com
Brief Descriptions : | |
Solar Panel Grounding Clips for PV Modules 8H for earthing kits | |
Item type: | Solar Panel Mounting Kits |
Technical Parameters : | |
Installation Site : | solar panel installation |
Profile Material : | SUS304 Stainless Steel |
Color : | Zinc coating |
Wind Load : | 60 m / s |
Snow Load : | 1.4 KN/M2 |
Module Orientation : | Flat / Pitched |
Standards : | AS/NZS 1170 |
DIN 1055 | |
GB50009-2012 | |
IBC2009 | |
TUV | |
JIS C 8955 : 2011 | |
International Building Code IBC 2009 | |
California Building Code CBC 2010 | |
Warranty | 10 years |
Designed Life Span | 25 years |
Packing Details : | |
Inner : | Bubble bag+inner box+Carton |
Outer : | Wooden Box, Steel Pallet, MDF, etc |
Drawing & size for Solar Panel Grounding Clips SPC-GW-08

Drawing and size for Solar Panel Grounding Clips SPC-GW-08
Drawing sizes for PV module earth clamp clips 8H
Solar earth clamp plate 8H is designed for both residential and commercial mounting applications .
This grounding clamp allows installing on flat / pitched / tile / tin roofs, also suitable for ground PV module
mounting structure .

solar earth clamp plate, 8H
Features of solar panel earth clamp clips 8H :
– Robust , good quality in SUS 304 stainless steel materials ;
– Anti-corrosive ;
– Quick & fast installing, no drilling required ;
– Great compatible for versatile applications ;
– 12 Years warranty ;
PV module earth clamp washers are mandatory for earthing solar panel array frames in many countries
nowadays .
Factory direct solar panel grounding eargh washer 8H wholesale with size and drawing details
